LW300FV XCMG 3 Ton Front End Wheel Loader
-1. XCMG 3 Ton Wheel Loader Main Information.
The LW300FV wheel loader is an upgraded model launched on the basis of XCMG LW300FN, which is energy-saving and emission reduction, more reliable in quality, more economical in use, more comfortable in operation, more convenient in maintenance, energy-saving and efficient, and the performance of the whole machine is greatly improved. The vibration and noise of the whole machine are obviously reduced.
|
Description |
Specification |
Unit |
|
Rated operating load |
3000 |
kg |
|
Bucket capacity |
1.8 |
m³ |
|
Machine weight |
10600±200 |
kg |
|
Dump clearance at maximum lift |
2930 |
mm |
|
Reach at maximum lift |
1010 |
mm |
|
Wheel base |
2600 |
mm |
|
Tread |
1850 |
mm |
|
Max. breakout force |
130±5 |
Kn |
|
Max. horse power |
95±5 |
Kn |
|
Total hydraulic cycle time |
8.8 |
s |
|
Min. turning radius over tyres |
5165±50 |
mm |
|
Articulation angle |
35 |
° |
|
Overall machine dimension LxWxH |
7245x2482x3050-3210 |
mm |
|
Engine Model |
WP6G125E333 |
|
|
Rated power/Speed |
92/2000 |
Kw/rpm |
-2. XCMG 3 Ton Wheel Loader Main Advantage.
The 3 ton wheel loader electrical system adopts fully-sealed connectors, and the dustproof and waterproof performance is obviously improved. Using centralized fuse box, inspection and maintenance is more convenient and efficient. CAN bus instrument and engine realize seamless connection; key electrical components are arranged in the cab, which is the same as that of international famous brands
The 3 ton wheel loader equipped with service brake and parking brake. The service brake adopts air-over oil caliper disc four-wheel brake, which has the advantages of stable braking, safe and reliable, simple structure and convenient maintenance. The afterburner pump is equipped with a dust-proof large-flow respirator, which is easy to maintain and improve the cleanliness of the afterburner pump and other components.
