Promotion ! XCMG LW500FN Wheel Loader For Sale

Promotion ! XCMG LW500FN Wheel Loader For Sale
Promotion ! XCMG LW500FN Wheel Loader For Sale
Promotion ! XCMG LW500FN Wheel Loader For Sale
Promotion ! XCMG LW500FN Wheel Loader For Sale
Promotion ! XCMG LW500FN Wheel Loader For Sale
Product Name : Promotion ! XCMG LW500FN Wheel Loader For Sale
Product ID : LW500FN
Working Weight : 5000kg
Bucket Capacity (Standard) : 2.5m3
Engine : WD10G220E21
Tire : 23.5-25-16PR
Max.Breakout Force : 170kN
Directions

-1. XCMG LW500FN Wheel Loader Information.



XCMG LW500FN could working for road, deck, port, warehouse etc construction. With the WEICHAI brand engine, mature tech and low maintenance cost, the air conditioner could optional also.





Description

Unit

Parameter value

Rated operating load

kg

5000 (LW500FN)

Bucket capacity

2.54.5

Machine weight

kg

16900

Dump clearance at maximum lift

mm

31503560

Reach at maximum lift

mm

11001190

Wheel base

mm

2960

Tread

mm

2250

Height of hinge at maximum lift height

mm

4112

Working height(fully lifted)

mm

5510

Max.breakout force

kN

170

Hydraulic cycle time-raise

s

≤6

Total hydraulic cycle time

s

≤10.5

Min. turning radius over tyres

mm

5950

Articulation angle

°

35

Gradeability

°

28



-2. XCMG LW500FN Wheel Loader Main Detail.





The LW500FN wheel loader could optional the grasping grass pliers , sliding fork, standard bucket and side dumping, meet the different work demand.



Also the LW500FN wheel loader engine work with WEICHAI, model is WD10G220E21 engine, maximum power reach to 162Kw.



The 170kN traction force and ≥3.5m high dumping capacity handle the severe conditions with ease.
