Product Name : BEIBEN 10 Tire 2638 Tipper Truck For DR Congo
Product ID : 2638
Engine : 380HP, EURO II
Gearbox : 9 forward and 1 reverse
Cabin : With one bed, A/C
Cargo Box : 5600x2300x1500mm
Tire : 12.00R20, 10+1 pcs
Directions

BEIBEN 10 Tire 2638 Tipper Truck Features



BEIBEN 2638 tipper truck adopt BENZ truck tech, with reliable quality and durable chassis. Its very popular in DR Congo, the BEIBEN tipper truck can very suitable for local mining material transport work.



-. BENZ truck axle, high power transmission and high load capacity.



-. WEICHAI 380HP engine, high engine performance and reduced fuel consumption.





BEIBEN 10 Tire 2638 Tipper Truck Specification



Description

Parameter Value

Product Name

BEIBEN 10 Tire 2638 Tipper Truck

Application

Transport mining material etc

Loading Capacity

30,000kg

Engine

WP10.380E32, 380HP, EURO II

Cabin

NG80B, with one bed, A/C, left hand drive

Gearbox

9JS150T, 9 forward and 1 reverse gear

Tire

12.00R20, 10+1 pcs, radial model

Steering

ZF8098, hydraulic boosting

Front Axle

7.5 ton, 2x7500kg

Driving Axle

13 ton, 2x13000kg

Fuel Tank

400L

Dimension

8400x2560x3450mm



The BEIBEN 10 tire 2638 tipper truck specification only for your reference, we will recommend other model BEIBEN tipper truck basic your request.



BEIBEN 10 Tire 2638 Tipper Truck Gearbox



BEIBEN 2638 tipper truck adopt the FAST brand gearbox, 9JS150A, mechanical type. Based on Fuller Eaton technology, 9 forward speed gear, 1 reverse gear. High transmission efficiency and low fuel consumption with the WEICHAI 380HP engine.
